48V DC Brushless Motor Logistics Sort Roller With Load 60kg Speed 300 - 1000rpm For Belt Sorting Conveyor

Features Overview of 48V DC Brushless Motor Logistics Sort Roller

The 48V DC Brushless Motor Logistics Sort Roller utilizes advanced technologies such as direct drive systems for quick responsiveness, brushless motor design for improved efficiency and reduced maintenance, and high-precision control mechanisms for accurate sorting. Additionally, it often incorporates dynamic response capabilities and low-noise operation to enhance performance in logistics applications.

Function of 48V DC Brushless Motor Logistics Sort Roller

• Direct Drive: Provides quick start-stop capabilities for efficient sorting.
• Precise Control: Ensures accurate motor speed and positioning for optimal sorting performance.
• Energy Efficiency: Reduces power consumption, lowering operational costs.
• Low Maintenance: Gearless design minimizes maintenance requirements and downtime.
• Dynamic Response: Achieves millisecond-level response times for rapid task handling.
• Noise Reduction: Operates quietly, suitable for noise-sensitive environments.
• High Load Capacity: Supports significant weights for reliable sorting under heavy loads.
• Temperature Resilience: Functions effectively in low-temperature environments down to -30°C.

Application of 48V DC Brushless Motor Logistics Sort Roller

1. E-commerce logistics
2. Express industry
3. Food industry
4. Packaging industry

Technical Parameters of 48V DC Brushless Motor Logistics Sort Roller

DC brushless motor parameters

The motor is composed of permanent magnet rotor and winding stator. This kind of motor has the advantages of simple structure, high reliability, good stability, high efficiency and strong adaptability, so it has been widely used. Because the brushless motor cancels the carbon brush, the motor itself cannot run, and needs to rely on the external drive card to run. Hall sensor is installed inside the motor to feed back the position signal to the drive card.

DC brushless servo motor parameters

The servo cylinder includes the cylinder shell, the cylinder shaft, the signal line, the permanent magnet brushless DC motor and the inductive encoder.

The inductive encoder includes the rotating module and the stator module. The rotating module rotates with the cylinder shell and interacts with the stator module to obtain the received signal. The high-precision position signal is calculated by the processing chip and transmitted to the motor control system, so as to accurately control the start and stop of the permanent magnet brushless DC motor Speed control and power density monitoring, etc.

The servo direct—drive electric roller described in this product has many advantages, such as compact structure, light weight, high position accuracy and large torque, and because the inductive position encoder adopts non-contact induction principle, itis suitable for working in various harsh environmental conditions, including wet, muddy and dusty working environment.

Feature Picture of 48V DC Brushless Motor Logistics Sort Roller

WINROLLER is a global manufacturer of advanced conveyor components, specializing in the development and production of miniature and small motors and conveyor rollers.

The company has won numbers of invention patents, and passed ISO9001 ans SGS quality system certification, EU CE certification, ROHS certification, UL certification and high-tech product certification.

Products are widely used in industrial automation, security checking machine, express logistics and other occasions.

We sincerely invite global cooperation agents, strategic partners, interested parties please contact the overseas Marketing Department.
